iCt Pro 12MP 30fps 1/1.7" IMX226 GigE/USB3.0 Rolling Shutter Area Scan Camera
Ship To Detecting...
Delivery: -
Product Description
The Rapixel iCt90M Pro 12MP Industrial Camera Series is a high-resolution machine vision solution designed for precision inspection, measurement, and industrial imaging applications. Powered by the Sony IMX226 CMOS sensor, this series delivers 12 megapixel resolution (4000 × 3000) with excellent image clarity, low noise, and high reliability.
To meet different system requirements, the series is available in both GigE and USB3.0 interface versions, providing flexible options for long-distance networking or high-speed data transfer.
🔹 Available Models
- iCt90M/CG120A-Pro (GigE): up to 9.7 FPS, ideal for long-distance and multi-camera systems
- iCt90M/CU120A-Pro (USB3.0): up to 30 FPS, suitable for higher-speed image acquisition
🔹 Key Features
- Sony IMX226 CMOS sensor for high image quality and stability
- 12MP ultra-high resolution for detailed inspection and measurement
- Choice of GigE or USB3.0 interface for flexible system integration
- Low noise and high dynamic performance
- Industrial-grade design for 24/7 continuous operation
- Compatible with mainstream machine vision software and SDKs
🔹 Typical Applications
- Precision industrial inspection
- Surface defect detection
- High-resolution measurement and metrology
- Electronics and semiconductor inspection
- Machine vision systems for automation and robotics
The Rapixel iCt90M Pro 12MP Series combines high resolution, stable performance, and flexible connectivity, making it an ideal choice for demanding industrial machine vision and inspection applications.
Specifications
| Model | iCt90M/CG120A-Pro | iCt90M/CU120A-Pro |
|---|---|---|
| Sensor | Sony IMX226 | Sony IMX226 |
| Sensor Size | 1/1.7'' | 1/1.7'' |
| Pixel Size | 1.85μm | 1.85μm |
| Resolution | 4024 x 3036 | 4024 x 3036 |
| Frame Rate | 9.7fps | 30fps |
| Interface | GigE | USB3.0 |
| Exposure Time | 28.4μs ~ 2sec | 28.4μs ~ 1sec |
| Dynamic Range | 69.3 dB | 70.6 dB |
| Interface | GigE | USB3.0 |
| Power Consumption | 2.15W (Typ. @12VDC) | 2.7W (USB3.0) |
| Operating System | Windows,Linux | Windows,Linux |
| Conformity | GigE Vision V2.0, GenICam compliant, 256MB on-board cache. | Compatible with U3 Vision protocol and GenICam standard |
Lens Specifications
Pairs well with
Contact info@rapixeltech.com if shipping fee is expensive!
Free SDK Provided
1-Year Warranty
iCt Pro 12MP 30fps 1/1.7" IMX226 GigE/USB3.0 Rolling Shutter Area Scan Camera
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Product details
Specifications
Resolution
Frame rate
Sensor
IMX226
Sensor size
1/1.7"
Pixel size
Interface
GigE
USB3.0
Shutter type
Mount
Supply voltage
Operating system
Windows
LinuX
Operating temperature
Purchase Note
🧾Notice for U.S. Customers
Due to applicable tariffs, please email your company name and FedEx, UPS, or DHL account number to info@rapixeltech.com after placing your order. (U.S. customers only)
💳 Transaction Fees Are Non-Refundable
When a refund is issued, please note that payment processing platforms do not return their service fees. These fees are not charged by our store, but by third-party providers (Shopify & PayPal). The handling fee will be deducted from a certain percentage of the order amount.(Depending on ways you paid: 2.5%-6%)
✅ Order Production Policy
All of our products are made to order or prepared specifically based on your purchase. We kindly ask customers to confirm their needs before placing an order. If you need assistance or further clarification before ordering, feel free to contact info@rapixeltech.com
Product FAQ
1. Lenses Not Included by Default
Industrial cameras are sold without lenses, as lens selection depends on your specific needs, such as field of view, working distance, resolution, and lighting.This differs from consumer cameras, which often have built-in lenses. We're happy to help you choose the right lens for your application.(info@rapixeltech.com)
2. No Internal Video Recording
Industrial cameras don't record video internally. They capture frames and transmit them in real time via USB, GigE, or Camera Link to a PC. Video recording must be handled by external software. If you simply need basic video recording, a consumer camera may be more suitable.
